Doris supports accessing AWS service resources through two authentication methods: ​​IAM User​​ and ​​Assumed Role​​. This article explains how to configure security credentials for both methods and use Doris features to interact with AWS services.

Authentication Methods Overview

IAM User Authentication​

Doris enables access to external data sources by configuring AWS IAM User credentials(equal to access_key and secret_key), below are the detailed configuration steps(for more information, refer to the AWS doc IAM users):

Step1 create an IAM User and configure policies​

  1. Login to the AWS Console and create an IAM User​

  1. Enter the IAM User name and attach policies directly​

  1. Define AWS resource policies in the policy editor​​, below are read/write policy templates for accessing an S3 bucket

S3 read policy template​，applies to Doris features requiring read/list access, e.g: S3 Load, TVF, External Catalog

Notes:

  1. Replace your-bucket and your-prefix with actual values.

  2. Avoid adding extra / separators.

{
    "Version": "2012-10-17",
    "Statement": [
        {
            "Effect": "Allow",
            "Action": [
              "s3:GetObject",
              "s3:GetObjectVersion",
            ],
            "Resource": "arn:aws:s3:::<your-bucket>/your-prefix/*"
        },
        {
            "Effect": "Allow",
            "Action": [
                "s3:ListBucket",
                "s3:GetBucketLocation"
            ],
            "Resource": "arn:aws:s3:::<your-bucket>"
        }
    ]
}

S3 write policy template​​ (Applies to Doris features requiring read/write access, e.g: Export, Storage Vault, Repository)

Notes:

  1. Replace your-bucket and your-prefix with actual values.

  2. Avoid adding extra / separators.

{
    "Version": "2012-10-17",
    "Statement": [
        {
            "Effect": "Allow",
            "Action": [
              "s3:PutObject",
              "s3:GetObject",
              "s3:GetObjectVersion",
              "s3:DeleteObject",
              "s3:DeleteObjectVersion",
              "s3:AbortMultipartUpload",
              "s3:ListMultipartUploadParts"
            ],
            "Resource": "arn:aws:s3:::<your-bucket>/<your-prefix>/*"
        },
        {
            "Effect": "Allow",
            "Action": [
                "s3:ListBucket",
                "s3:GetBucketLocation",
                "s3:GetBucketVersioning",
                "s3:GetLifecycleConfiguration"
            ],
            "Resource": "arn:aws:s3:::<your-bucket>"
        }
    ]
}
  1. After successfully creating the IAM User, create access/secret key pair

Step2 Use doris features with access/secret key pair via SQL​

After completing all configurations in Step 1, you will obtain access_key and secret_key. Use these credentials to access doris features as shown in the following examples:

S3 Load

  LOAD LABEL s3_load_2022_04_01
  (
      DATA INFILE("s3://your_bucket_name/s3load_example.csv")
      INTO TABLE test_s3load
      COLUMNS TERMINATED BY ","
      FORMAT AS "CSV"
      (user_id, name, age)
  )
  WITH S3
  (
      "provider" = "S3",
      "s3.endpoint" = "s3.us-east-1.amazonaws.com",
      "s3.region" = "us-east-1",
      "s3.access_key" = "<your-access-key>",
      "s3.secret_key" = "<your-secrety-key>"
  )
  PROPERTIES
  (
      "timeout" = "3600"
  );

TVF

  SELECT * FROM S3 (
      'uri' = 's3://your_bucket/path/to/tvf_test/test.parquet',
      'format' = 'parquet',
      's3.endpoint' = 's3.us-east-1.amazonaws.com',
      's3.region' = 'us-east-1',
      "s3.access_key" = "<your-access-key>",
      "s3.secret_key"="<your-secret-key>"
  )

External Catalog

  CREATE CATALOG iceberg_catalog PROPERTIES (
      'type' = 'iceberg',
      'iceberg.catalog.type' = 'hadoop',
      'warehouse' = 's3://your_bucket/dir/key',
      's3.endpoint' = 's3.us-east-1.amazonaws.com',
      's3.region' = 'us-east-1',
      "s3.access_key" = "<your-access-key>",
      "s3.secret_key"="<your-secret-key>"
  );

Storage Vault

CREATE STORAGE VAULT IF NOT EXISTS s3_demo_vault
PROPERTIES (
    "type" = "S3",
    "s3.endpoint" = "s3.us-east-1.amazonaws.com",
    "s3.region" = "us-east-1",
    "s3.bucket" = "<your-bucket>",
    "s3.access_key" = "<your-access-key>",
    "s3.secret_key"="<your-secret-key>",
    "s3.root.path" = "s3_demo_vault_prefix",
    "provider" = "S3",
    "use_path_style" = "false"
);

Export

EXPORT TABLE s3_test TO "s3://your_bucket/a/b/c"
PROPERTIES (
    "column_separator"="\\x07",
    "line_delimiter" = "\\x07"
) WITH S3 (
    "s3.endpoint" = "s3.us-east-1.amazonaws.com",
    "s3.region" = "us-east-1",
    "s3.access_key" = "<your-access-key>",
    "s3.secret_key"="<your-secret-key>",
)

Repository

CREATE REPOSITORY `s3_repo`
WITH S3
ON LOCATION "s3://your_bucket/s3_repo"
PROPERTIES
(
    "s3.endpoint" = "s3.us-east-1.amazonaws.com",
    "s3.region" = "us-east-1",
    "s3.access_key" = "<your-access-key>",
    "s3.secret_key"="<your-secret-key>"
);

Resource

CREATE RESOURCE "remote_s3"
PROPERTIES
(
    "s3.endpoint" = "s3.us-east-1.amazonaws.com",
    "s3.region" = "us-east-1",
    "s3.bucket" = "<your-bucket>",
    "s3.access_key" = "<your-access-key>",
    "s3.secret_key"="<your-secret-key>"
);

You can specify different IAM User credentials (access_key and secret_key) across different business logic to implement access control for external data.

Assumed Role Authentication​

Assumed Role allows accessing external data sources by assuming an AWS IAM Role(for details, refer to AWS documentation assume role), the following diagram illustrates the configuration workflow:

Terminology:

Source Account: The AWS account initiating the Assume Role action (where Doris FE/BE EC2 instances reside);

Target Account: The AWS account owning the target S3 bucket;

Note: The source and target accounts can be the same AWS account

ec2_role: A role created in the source account, attached to EC2 instances running Doris FE/BE;

bucket_role: A role created in the target account with permissions to access the target bucket;

​​More detailed configuration steps are as follows:​

Step1 Prerequisites​

  1. Ensure the source account has created an ec2_role and attached it to all EC2 instances running Doris FE/BE;

  2. Ensure the target account has created a bucket_role and corresponding bucket;

After attaching ec2_role to EC2 instances, you can find the role_arn as shown below:

Step2 Configure Permissions for Source Account IAM Role (EC2 Instance Role)​

  1. Log in to the AWS IAM Console，navigate to ​​Access management > Roles；
  2. Find the EC2 instance role and click its name;
  3. On the role details page, go to the ​​Permissions​​ tab, click ​​Add permissions​​, then select ​​Create inline policy​​;
  4. In the ​​Specify permissions​​ section, switch to the ​​JSON​​ tab, paste the following policy, and click ​​Review policy​​:

{
    "Version": "2012-10-17",
    "Statement": [
        {
            "Effect": "Allow",
            "Action": ["sts:AssumeRole"],
            "Resource": "*"
        }
    ]
}

Step3 Configure Trust Policy and Permissions for Target Account IAM Role​

  1. Log in AWS IAM Console, navigate to ​​Access management > Roles​​, find the target role (bucket_role), and click its name;

  2. Go to the ​​Trust relationships​​ tab, click ​​Edit trust policy​​, and paste the following JSON (replace <ec2_iam_role_arn> with your EC2 instance role ARN). Click ​​Update policy

Note: The ExternalId in the Condition section is an optional string parameter used to distinguish scenarios where multiple source users need to assume the same role. If configured, include it in the corresponding Doris SQL statements. For a detailed explanation of ExternalId, refer to aws doc

{
    "Version": "2012-10-17",
    "Statement": [
        {
            "Effect": "Allow",
            "Principal": {
                "AWS": "<ec2_iam_role_arn>"
            },
            "Action": "sts:AssumeRole",
            "Condition": {
                "StringEquals": {
                    "sts:ExternalId": "1001"
                }
            }
        }
    ]
}
  1. On the role details page, go to the ​​Permissions​​ tab, click ​​Add permissions​​, then select ​​Create inline policy​​. In the ​​JSON​​ tab, paste one of the following policies based on your requirements;

S3 read policy template​，applies to Doris features requiring read/list access, e.g: S3 Load, TVF, External Catalog

Notes:

  1. Replace your-bucket and your-prefix with actual values.

  2. Avoid adding extra / separators.

{
    "Version": "2012-10-17",
    "Statement": [
        {
            "Effect": "Allow",
            "Action": [
              "s3:GetObject",
              "s3:GetObjectVersion"
            ],
            "Resource": "arn:aws:s3:::<bucket>/<prefix>/*"
        },
        {
            "Effect": "Allow",
            "Action": [
                "s3:ListBucket",
                "s3:GetBucketLocation"
            ],
            "Resource": "arn:aws:s3:::<bucket>",
        }
    ]
}

S3 write policy template​​ (Applies to Doris features requiring read/write access, e.g: Export, Storage Vault, Repository)

Notes:

  1. Replace your-bucket and your-prefix with actual values.

  2. Avoid adding extra / separators.

{
    "Version": "2012-10-17",
    "Statement": [
        {
            "Effect": "Allow",
            "Action": [
              "s3:PutObject",
              "s3:GetObject",
              "s3:GetObjectVersion",
              "s3:DeleteObject",
              "s3:DeleteObjectVersion",
              "s3:AbortMultipartUpload",
              "s3:ListMultipartUploadParts"
            ],
            "Resource": "arn:aws:s3:::<bucket>/<prefix>/*"
        },
        {
            "Effect": "Allow",
            "Action": [
                "s3:ListBucket",
                "s3:GetBucketLocation"
            ],
            "Resource": "arn:aws:s3:::<bucket>"
        }
    ]
}

Step4 Use doris features with Assumed Role via SQL, according to role_arn and external_id fields;​

After completing the above configurations, obtain the target account's role_arn and external_id (if applicable). Use these parameters in doris SQL statements as shown below:

Common important key parameters:​​

"s3.role_arn" = "<your-target-role-arn>",
"s3.external_id" = "<your-external-id>"      -- option parameter

S3 Load

  LOAD LABEL s3_load_2022_04_01
  (
      DATA INFILE("s3://your_bucket_name/s3load_example.csv")
      INTO TABLE test_s3load
      COLUMNS TERMINATED BY ","
      FORMAT AS "CSV"
      (user_id, name, age)
  )
  WITH S3
  (
      "provider" = "S3",
      "s3.endpoint" = "s3.us-east-1.amazonaws.com",
      "s3.region" = "us-east-1",
      "s3.role_arn" = "<your-target-role-arn>",
      "s3.external_id" = "<your-external-id>"      -- option parameter
  )
  PROPERTIES
  (
      "timeout" = "3600"
  );

TVF

  SELECT * FROM S3 (
      "uri" = "s3://your_bucket/path/to/tvf_test/test.parquet",
      "format" = "parquet",
      "s3.endpoint" = "s3.us-east-1.amazonaws.com",
      "s3.region" = "us-east-1",
      "s3.role_arn" = "<your-target-role-arn>",
      "s3.external_id" = "<your-external-id>"      -- option parameter
  )

External Catalog

  CREATE CATALOG iceberg_catalog PROPERTIES (
      "type" = "iceberg",
      "iceberg.catalog.type" = "hadoop",
      "warehouse" = "s3://your_bucket/dir/key",
      "s3.endpoint" = "s3.us-east-1.amazonaws.com",
      "s3.region" = "us-east-1",
      "s3.role_arn" = "<your-target-role-arn>",
      "s3.external_id" = "<your-external-id>"      -- option parameter
  );

Storage Vault

CREATE STORAGE VAULT IF NOT EXISTS s3_demo_vault
PROPERTIES (
    "type" = "S3",
    "s3.endpoint" = "s3.us-east-1.amazonaws.com",
    "s3.region" = "us-east-1",
    "s3.bucket" = "<your-bucket>",
    "s3.role_arn" = "<your-target-role-arn>",
    "s3.external_id" = "<your-external-id>",            -- option parameter
    "s3.root.path" = "s3_demo_vault_prefix",
    "provider" = "S3",
    "use_path_style" = "false"
);

Export

EXPORT TABLE s3_test TO "s3://your_bucket/a/b/c"
PROPERTIES (
    "column_separator"="\\x07",
    "line_delimiter" = "\\x07"
) WITH S3 (
    "s3.endpoint" = "s3.us-east-1.amazonaws.com",
    "s3.region" = "us-east-1",
    "s3.role_arn" = "<your-target-role-arn>",
    "s3.external_id" = "<your-external-id>"
)

Repository

CREATE REPOSITORY `s3_repo`
WITH S3
ON LOCATION "s3://your_bucket/s3_repo"
PROPERTIES
(
    "s3.endpoint" = "s3.us-east-1.amazonaws.com",
    "s3.region" = "us-east-1",
    "s3.role_arn" = "<your-target-role-arn>",
    "s3.external_id" = "<your-external-id>"
);

Resource

CREATE RESOURCE "remote_s3"
PROPERTIES
(
    "s3.endpoint" = "s3.us-east-1.amazonaws.com",
    "s3.region" = "us-east-1",
    "s3.bucket" = "<your-bucket>",
    "s3.role_arn" = "<your-target-role-arn>",
    "s3.external_id" = "<your-external-id>"
);
